Growatt 4KW 5KW 6KW 7KW 8KW 10KW Hybrid Off-grid Solar Inverter
|
Datasheet |
SPH 4000TL3 BH |
SPH 5000TL3 BH |
SPH 6000TL3 BH |
SPH 7000TL3 BH |
SPH 8000TL3 BH |
SPH 10000TL3 BH |
|
|
Input data(PV) |
|||||||
|
Max. recommended PV power (for module STC) |
5200W |
6500W |
7800W |
9100W |
10400W |
13000W |
|
|
Max. DC voltage |
1000 |
||||||
|
Start voltage |
160V |
||||||
|
MPP voltage range |
160V-1000V / 600V |
||||||
|
No. of MPP trackers |
2 |
||||||
|
No. of PV strings per MPP tracker |
1 |
||||||
|
Max. input current per MPP tracker |
12A |
||||||
|
Max. short-circuit current per MPP tracker |
15A |
||||||
|
Output data(AC) |
|||||||
|
AC nominal power |
4000W |
5000W |
6000W |
7000W |
8000W |
10000W |
|
|
Max. AC apparent power |
4000VA |
5000VA |
6000VA |
7000VA |
8000VA |
10000VA |
|
|
Nominal AC voltage (range*) |
230V/400V (310~476V) |
||||||
|
AC grid frequency (range*) |
50Hz/60Hz (45Hz-55Hz/55Hz-65Hz) |
||||||
|
Max. output current |
6.1A |
7.6A |
9.1A |
10.6A |
12.1A |
15.2A |
|
|
Adjustable power factor |
0.8leading…0.8lagging |
||||||
|
THDi |
<3% |
||||||
|
AC grid connection type |
3W+N+PE |
||||||
|
Battery data (DC) |
|||||||
|
Battery voltage range |
100~550V |
||||||
|
Max charging and discharging current |
25A |
||||||
|
Continuous charging and discharging power |
4000W |
5000W |
6000W |
7000W |
8000W |
10000W |
|
|
Type of battery |
Lithium battery |
||||||
|
Backup power(AC) |
|||||||
|
Max. AC output power |
4000W |
5000W |
6000W |
7000W |
8000W |
10000W |
|
|
Max. AC apparent power |
4000VA |
5000VA |
6000VA |
7000VA |
8000VA |
10000VA |
|
|
Max. output current |
6.1A |
7.6A |
9.1A |
10.6A |
12.1A |
15.2A |
|
|
Nominal AC output voltage |
230V/400V |
||||||
|
Nominal AC output frequency |
50/60HZ |
||||||
|
THDv |
<3% |
||||||
|
Switch time |
<0.5S |
||||||
|
Efficiency |
|||||||
|
MAX. efficiency |
97.6% |
97.8% |
98.0% |
98.2% |
98.2% |
98.2% |
|
|
European efficiency |
97.0% |
97.2% |
97.3% |
97.4% |
97.4% |
97.5% |
|
|
Protection devices |
|||||||
|
DC switch |
yes |
||||||
|
DC reverse polarity protection |
yes |
||||||
|
AC/DC surge protection |
Type II |
||||||
|
Battery reverse protection |
yes |
||||||
|
AC short-circuit protection |
yes |
||||||
|
Ground fault monitoring |
yes |
||||||
|
Grid monitoring |
yes |
||||||
|
Anti-islanding protection |
yes |
||||||
|
Residual-current monitoring unit |
yes |
||||||
|
Insulation resistance monitoring |
yes |
||||||
|
General data |
|||||||
|
Dimensions (W / H / D) |
505/453/198mm |
||||||
|
Weight |
28kg |
||||||
|
Operating temperature range |
–25 °C ... +60 °C |
||||||
|
Noise emission (typical) |
≤ 35 dB(A) |
||||||
|
Nighttime power consumption |
<13W |
||||||
|
Topology |
Transformerless |
||||||
|
Cooling |
Natural |
||||||
|
Protection degree |
IP65 |
||||||
|
Relative humidity |
0~100% |
||||||
|
Altitude |
3000m |
||||||
|
DC connection |
H4 / MC4 (opt ) |
||||||
|
AC connection |
Connector |
||||||
|
Display |
LCD+LED |
||||||
|
Interfaces: RS232/RS485/CAN/USB |
yes |
||||||
|
Monitor : RF/WIFI/GPRS |
opt |
||||||
|
Warranty: 5 years / 10 years |
yes / opt |
||||||
|
IEC 61000, IEC 62109, IEC 62040, VDE-AR-N 4105, VDE 0126, UTE C 15-712, En50549, CEI 0-21IEC62116, IEC61727, AS/NZS 4777, G98, IEC 62477, C10/11 , UNE217001 , UNE206007 , PO12.2, TOR Erzeuger |
|||||||
